Tailored machine design
Complete conceptualization and engineering of bespoke industrial machinery and heavy-duty systems, integrated with high-pressure fluid power infrastructure.
Mobile Hydraulic Engineering
Custom Hydraulic Machinery & Systems Engineering
Transforming complex technical requirements into high-performance, turnkey industrial machinery. Backed by over 25 years of engineering experience tailored exactly to your operations.
Engineering
Engineering capabilities
From machine concept to component selection and hydraulic documentation — one independent desk.
Component optimization
Precise selection, flow calculation and placement of hydraulic elements for efficiency, reliability and a long life under high load.
Mobile hydraulics
Systems for working machines, drives and attachments: multi-axis synchronization, proportional control, supply and overload protection.
CAD documentation
Standard-compliant hydraulic schematics, bills of materials and build documentation.
Components
Hydraulic components sourcing
Cylinders, valves, manifolds — sized for your forces, strokes and duty cycle.
Custom hydraulic cylinders
Send a sketch and your assumptions — you receive a production-ready hydraulic cylinder design.
Tools
Hydraulic calculators
Cylinder force, then power-unit power from flow and pressure — the two numbers a brief usually starts with.
Tool 01
Hydraulic cylinder force
A quick estimate of push and pull force. It does not replace a full design — it shows the order of magnitude.
20 mm400 mm
10 mm76 mm
10 bar700 bar
Push force
80.4 kN
Pull force
55.0 kN
F = p · A. 1 bar = 0.1 N/mm². Pull force subtracts rod area. Estimate only — final selection must check buckling, seals and design margin.
Tool 02
Power unit power
Hydraulic power of an aggregate from oil flow and pressure. Use it to size the pump drive.
5 l/min400 l/min
10 bar420 bar
70 %98 %
Hydraulic power
28.0 kW
Shaft power
31.1 kW
Suggested motor
37 kW
Flow × pressure
80 × 210
P [kW] = Q [l/min] × p [bar] / 600. Shaft power divides by pump efficiency. Estimate only — a real power pack also needs heat balance, duty cycle and starting torque.
Contact
Ready to build your custom solution?
Describe the machine, the forces and the duty. You get a scoped reply — not a template quote.
